ONE
The well-designed adsorption tower ensures that the saturated air entering the dryer is dried to the required dew point and compensates for the natural aging of the adsorbent layer; the large stainless steel air diffuser with reliable structure enables the air flow to pass through the adsorbent layer evenly to eliminate the channeling phenomenon; appropriate tower size and convection mode of upstream drying and downstream regeneration are conducive to reducing the amount of regeneration air flow, and avoiding adsorbent fluidization and adsorbent layer pollution; the slow and complete charging procedure and delay switching design can eliminate the downstream airflow ripple and prevent the adsorbent movement and abrasion;
TWO
It has the advantages of high safety, easy maintenance and safe and reliable functions.
ONE
The well-designed adsorption tower ensures that the saturated air entering the dryer is dried to the required dew point and compensates for the natural aging of the adsorbent layer; the large stainless steel air diffuser with reliable structure enables the air flow to pass through the adsorbent layer evenly to eliminate the channeling phenomenon; appropriate tower size and convection mode of upstream drying and downstream regeneration are conducive to reducing the amount of regeneration air flow, and avoiding adsorbent fluidization and adsorbent layer pollution; the slow and complete charging procedure and delay switching design can eliminate the downstream airflow ripple and prevent the adsorbent movement and abrasion;
TWO
It has the advantages of high safety, easy maintenance and safe and reliable functions.
ITEM Type | Air flow rates(m³/min) | Air connection(mm) | Dimensions(mm) | Heater power(Kw/v) | Net weight(Kg) | |||
Lenght | Width | Hingh | Heatless | Microheat | ||||
DE005 | 0.8 | DN15 | 560 | 350 | 1420 | / | 70 | / |
DE010 | 1.8 | DN20 | 650 | 400 | 1720 | / | 80 | / |
DE020(LH) | 2.8 | DN20 | 700 | 450 | 1750 | / | 100 | / |
DE030(LH) | 3.8 | DN25 | 800 | 450 | 1800 | 0.5/220 | 130 | 140 |
DE050(LH) | 5.5 | DN40 | 1000 | 650 | 1800 | 0.75/220 | 250 | 270 |
DE070(LH) | 6.8 | DN40 | 1000 | 650 | 1800 | 1.25/220 | 280 | 300 |
DE100(LH) | 11.5 | DN50 | 1160 | 760 | 1900 | 2.5/220 | 500 | 530 |
DE120(LH) | 14 | DN65 | 1160 | 760 | 2050 | 3/220 | 550 | 580 |
DE150(LH) | 16 | DN65 | 1260 | 800 | 2000 | 3.75/380 | 600 | 620 |
DE200(LH) | 22.8 | DN80 | 1500 | 1000 | 2050 | 5/380 | 860 | 900 |
DE250(LH) | 28.5 | DN80 | 1600 | 1000 | 2200 | 6.5/380 | 1200 | 1250 |
DE300(LH) | 35 | DN80 | 1700 | 1100 | 2200 | 7.5/380 | 1600 | 1700 |
DE400(LH) | 45 | DN100 | 1800 | 1100 | 2400 | 10/380 | 1900 | 2000 |
DE500(LH) | 55 | DN100 | 2100 | 1100 | 2500 | 12.5/380 | 2300 | 2500 |
DE600(LH) | 65 | DN125 | 2300 | 1200 | 2650 | 15/380 | 2800 | 3000 |
DE800(LH) | 85 | DN150 | 2500 | 1300 | 2900 | 20/380 | 3400 | 3800 |
DE1000(LH) | 105 | DN150 | 3000 | 1500 | 3000 | 25/308 | 4100 | 4500 |
DE1200(LH) | 120 | DN200 | 3200 | 1600 | 3000 | 30/380 | 4500 | 5000 |
DE1600(LH) | 160 | DN200 | 3800 | 1800 | 3000 | 40/380 | 6000 | 6500 |
DE2000(LH) | 200 | DN250 | 4200 | 2000 | 3000 | 50/380 | 7500 | 8000 |
ITEM Type | Air flow rates(m³/min) | Air connection(mm) | Dimensions(mm) | Heater power(Kw/v) | Net weight(Kg) | |||
Lenght | Width | Hingh | Heatless | Microheat | ||||
DE005 | 0.8 | DN15 | 560 | 350 | 1420 | / | 70 | / |
DE010 | 1.8 | DN20 | 650 | 400 | 1720 | / | 80 | / |
DE020(LH) | 2.8 | DN20 | 700 | 450 | 1750 | / | 100 | / |
DE030(LH) | 3.8 | DN25 | 800 | 450 | 1800 | 0.5/220 | 130 | 140 |
DE050(LH) | 5.5 | DN40 | 1000 | 650 | 1800 | 0.75/220 | 250 | 270 |
DE070(LH) | 6.8 | DN40 | 1000 | 650 | 1800 | 1.25/220 | 280 | 300 |
DE100(LH) | 11.5 | DN50 | 1160 | 760 | 1900 | 2.5/220 | 500 | 530 |
DE120(LH) | 14 | DN65 | 1160 | 760 | 2050 | 3/220 | 550 | 580 |
DE150(LH) | 16 | DN65 | 1260 | 800 | 2000 | 3.75/380 | 600 | 620 |
DE200(LH) | 22.8 | DN80 | 1500 | 1000 | 2050 | 5/380 | 860 | 900 |
DE250(LH) | 28.5 | DN80 | 1600 | 1000 | 2200 | 6.5/380 | 1200 | 1250 |
DE300(LH) | 35 | DN80 | 1700 | 1100 | 2200 | 7.5/380 | 1600 | 1700 |
DE400(LH) | 45 | DN100 | 1800 | 1100 | 2400 | 10/380 | 1900 | 2000 |
DE500(LH) | 55 | DN100 | 2100 | 1100 | 2500 | 12.5/380 | 2300 | 2500 |
DE600(LH) | 65 | DN125 | 2300 | 1200 | 2650 | 15/380 | 2800 | 3000 |
DE800(LH) | 85 | DN150 | 2500 | 1300 | 2900 | 20/380 | 3400 | 3800 |
DE1000(LH) | 105 | DN150 | 3000 | 1500 | 3000 | 25/308 | 4100 | 4500 |
DE1200(LH) | 120 | DN200 | 3200 | 1600 | 3000 | 30/380 | 4500 | 5000 |
DE1600(LH) | 160 | DN200 | 3800 | 1800 | 3000 | 40/380 | 6000 | 6500 |
DE2000(LH) | 200 | DN250 | 4200 | 2000 | 3000 | 50/380 | 7500 | 8000 |
