0.7, 0.8, 1.0, 1.3
45
Model | Mpa | BG |
power | KW | 45 |
flow(m³/min) | Displacement/m³/min pressure/Mpa | 9.8/0.7 |
9.7/0.8 | ||
7.8/1.0 | ||
6.5/1.3 | ||
outlet pipe | Inch | G2" |
weight | kg | 1500 |
dimension | Length | 1850 |
width | 1350 | |
height | 1530 | |
start type | Star Triangle Start |
Model | Mpa | BG |
power | KW | 45 |
flow(m³/min) | Displacement/m³/min pressure/Mpa | 9.8/0.7 |
9.7/0.8 | ||
7.8/1.0 | ||
6.5/1.3 | ||
outlet pipe | Inch | G2" |
weight | kg | 1500 |
dimension | Length | 1850 |
width | 1350 | |
height | 1530 | |
start type | Star Triangle Start |
